ENWW
*Notified body number (used only if
applicable — refer to the product label).
German Ergonomics Notice
HP products which bear the “GS” approval mark, when forming part of a system comprising HP
brand computers, keyboards and monitors that bear the “GS” approval mark, meet the applicable
ergonomic requirements. The installation guides included with the products provide configuration
information.
Japanese Notice
Korean Notice
Power Cord Set Requirements
The monitor power supply is provided with Automatic Line Switching (ALS). This feature allows the
monitor to operate on input voltages between 100–120V or 200–240V.
The power cord set (flexible cord or wall plug) received with the monitor meets the requirements for
use in the country where you purchased the equipment.
If you need to obtain a power cord for a different country, you should purchase a power cord that is
approved for use in that country.
The power cord must be rated for the product and for the voltage and current marked on the
product's electrical ratings label. The voltage and current rating of the cord should be greater than
the voltage and current rating marked on the product. In addition, the cross-sectional area of the wire
must be a minimum of 0.75 mm² or 18 AWG, and the length of the cord must be between 6 feet (1.8
m) and 12 feet (3.6 m). If you have questions about the type of power cord to use, contact an
authorized HP service provider.
A power cord should be routed so that it is not likely to be walked on or pinched by items placed
upon it or against it. Particular attention should be paid to the plug, electrical outlet, and the point
where the cord exits from the product.
German Ergonomics Notice 45

Table of Contents

Other manuals for HP LP1965

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP LP1965 and is the answer not in the manual?

HP LP1965 Specifications

General IconGeneral
Operating temperature (T-T)5 - 35 °C
Non-operating relative humidity (non-condensing)5 - 90 %
Pivot angle0 - 90 °
Plug and PlayYes
Tilt angle range-4 - 30 °
Height adjustment100 mm
Cable lock slot typeKensington
Panel mounting interface100 x 100 mm
3DNo
HD type-
Panel typeTFT
Pixel pitch0.294 x 0.294 mm
Aspect ratio4:3
Response time6 ms
Display surfaceMatt
Display diagonal19 \
Display resolution1280 x 1024 pixels
Display technologyLCD
Vertical scan range48 - 76 Hz
Horizontal scan range24 - 83 kHz
Contrast ratio (typical)1000:1
Display number of colors16.78 million colors
Display scanning frequencyHorizontal frequency: 24-83 kHz, Vertical frequency: 48-76 Hz
Display brightness (typical)300 cd/m²
Supported graphics resolutions1280 x 1024 (SXGA)
UNSPSC-code43211902
Audio includedNo audio included No audio included at platform level
Rear ports note4 USB 2.0
Native resolutionSXGA (1280x1024) pixels
Security featuresKensington Lock-ready
Weight (imperial)15.6 lb lbs
Power requirementsAuto-ranging, 90 to 265 VAC, Internal power supply, 50 to 60 Hz (built-in power supply)
Recommended resolutionPreset VESA Graphic Modes (non-interlaced): 1280 x 1024 @ 60 and 75 Hz, 1024 x 768 @ 60, 70 and 75 Hz, 1152 x 870 @ 75 Hz (Mac), 1152 x 900 @ 76 Hz (Sun), 832 x 624 @ 75 Hz (Mac), 800 x 600 @ 60, 72 and 75 Hz, 720 x 400 @ 70 Hz, 640 x 480 @ 60, 72 and 75
Display resolution at frequencyPreset VESA Graphic Modes (non-interlaced): 1280 x 1024 @ 60 and 75 Hz, 1024 x 768 @ 60, 70 and 75 Hz, 1152 x 870 @ 75 Hz (Mac), 1152 x 900 @ 76 Hz (Sun), 832 x 624 @ 75 Hz (Mac), 800 x 600 @ 60, 72 and 75 Hz, 720 x 400 @ 70 Hz, 640 x 480 @ 60, 72 and 75 Hz
Dimensions (W x D x H) (imperial)15.9 x 8.78 x 18.79 \
Product dimensions (without stand, imperial)15.9 x 2.4 x 12.96 \
Product colorBlack, Silver
Country of originChina
AC input voltage90 - 265 V
AC input frequency50 - 60 Hz
Power consumption (max)55 W
Power consumption (standby)2 W
Power consumption (typical)35 W
I/O portsOne upstream, four downstream ports (cable included)
USB hub version2.0
DVI-D ports quantity0
DVI-I ports quantity2
USB Type-A downstream ports quantity3
Cables includedAC, DVI
Interface adapters includedDVI-I female - VGA male
Weight and Dimensions IconWeight and Dimensions
Depth (with stand)222.9 mm
Width (with stand)403.9 mm
Height (with stand)377.2 mm
Weight (with stand)7060 g
Depth (without stand)61 mm
Height (without stand)329.1 mm
Weight (without stand)4190 g
