ENWW
Table 4-3 HP Display LiteSaver Configuration Options (continued)
Select This Option To Do This
Display Off Sets the time when the monitor automatically turns off. This does not affect
screen saver operation, which has priority over the HP Display LiteSaver.
Display On Sets the time when the monitor automatically turns on. This does not affect
screen saver operation, which has priority over the HP Display LiteSaver.
Activity Extension Sets the time in minutes before the monitor turns off if there is any keyboard or
mouse activity after the Display Off time is reached. If the keyboard or mouse is
used, then HP Display LiteSaver waits until the set amount of time before turning
the display off again. Set to 0 to disable. If disabled, the monitor will turn off as
soon as the Display Off time is reached, regardless of keyboard or mouse activity.
Show 1 minute Display Off Notice Displays a popup message in the system tray 1 minute before the monitor is
turned off by HP Display LiteSaver.
Status Shows the time until the monitor is next due to be turned off by HP Display
LiteSaver.
OK Stores the current settings and minimizes HP Display LiteSaver to the System
Tray.
Cancel Restores the previous settings and minimizes HP Display LiteSaver to the
System Tray. HP Display LiteSaver will continue to run.
Help Opens the online help file.
Exit Exits and closes the HP Display LiteSaver. It will no longer control the monitor
power until it is next run.
View HP Display LiteSaver Readme on the CD for additional information on how to configure HP
Display LiteSaver.
sRGB Support
The monitor is designed to support sRGB for color management, which adapts to the color standards
used in the image technology industry.
To take advantage of the sRGB support, you will need to change the monitor’s color temperature to
sRGB and install the sRGB color profile (ICM) file.
NOTE The sRGB color temperature preset will improve the color accuracy of sRGB images
on the computer monitor, but some color variation may still occur.
Changing the Color Temperature
1. Press the Menu button on the front panel of the monitor to launch the Main Menu of the OSD.
2. Select Advanced Menu to access all options in the Main Menu.
3. Select Color to display the Color Temperature menu.
4. Select sRGB.
5. Select Save and Return to exit the menu.
sRGB Support 31

Table of Contents

Other manuals for HP LP1965

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP LP1965 and is the answer not in the manual?

HP LP1965 Specifications

General IconGeneral
Operating temperature (T-T)5 - 35 °C
Non-operating relative humidity (non-condensing)5 - 90 %
Pivot angle0 - 90 °
Plug and PlayYes
Tilt angle range-4 - 30 °
Height adjustment100 mm
Cable lock slot typeKensington
Panel mounting interface100 x 100 mm
3DNo
HD type-
Panel typeTFT
Pixel pitch0.294 x 0.294 mm
Aspect ratio4:3
Response time6 ms
Display surfaceMatt
Display diagonal19 \
Display resolution1280 x 1024 pixels
Display technologyLCD
Vertical scan range48 - 76 Hz
Horizontal scan range24 - 83 kHz
Contrast ratio (typical)1000:1
Display number of colors16.78 million colors
Display scanning frequencyHorizontal frequency: 24-83 kHz, Vertical frequency: 48-76 Hz
Display brightness (typical)300 cd/m²
Supported graphics resolutions1280 x 1024 (SXGA)
UNSPSC-code43211902
Audio includedNo audio included No audio included at platform level
Rear ports note4 USB 2.0
Native resolutionSXGA (1280x1024) pixels
Security featuresKensington Lock-ready
Weight (imperial)15.6 lb lbs
Power requirementsAuto-ranging, 90 to 265 VAC, Internal power supply, 50 to 60 Hz (built-in power supply)
Recommended resolutionPreset VESA Graphic Modes (non-interlaced): 1280 x 1024 @ 60 and 75 Hz, 1024 x 768 @ 60, 70 and 75 Hz, 1152 x 870 @ 75 Hz (Mac), 1152 x 900 @ 76 Hz (Sun), 832 x 624 @ 75 Hz (Mac), 800 x 600 @ 60, 72 and 75 Hz, 720 x 400 @ 70 Hz, 640 x 480 @ 60, 72 and 75
Display resolution at frequencyPreset VESA Graphic Modes (non-interlaced): 1280 x 1024 @ 60 and 75 Hz, 1024 x 768 @ 60, 70 and 75 Hz, 1152 x 870 @ 75 Hz (Mac), 1152 x 900 @ 76 Hz (Sun), 832 x 624 @ 75 Hz (Mac), 800 x 600 @ 60, 72 and 75 Hz, 720 x 400 @ 70 Hz, 640 x 480 @ 60, 72 and 75 Hz
Dimensions (W x D x H) (imperial)15.9 x 8.78 x 18.79 \
Product dimensions (without stand, imperial)15.9 x 2.4 x 12.96 \
Product colorBlack, Silver
Country of originChina
AC input voltage90 - 265 V
AC input frequency50 - 60 Hz
Power consumption (max)55 W
Power consumption (standby)2 W
Power consumption (typical)35 W
I/O portsOne upstream, four downstream ports (cable included)
USB hub version2.0
DVI-D ports quantity0
DVI-I ports quantity2
USB Type-A downstream ports quantity3
Cables includedAC, DVI
Interface adapters includedDVI-I female - VGA male
Weight and Dimensions IconWeight and Dimensions
Depth (with stand)222.9 mm
Width (with stand)403.9 mm
Height (with stand)377.2 mm
Weight (with stand)7060 g
Depth (without stand)61 mm
Height (without stand)329.1 mm
Weight (without stand)4190 g
