HP LP1965 User Manual

ENWW
Table 4-2 OSD Menu (continued)
Icon Main Menu Submenu Description
9300 K Changes to slightly blueish white.
6500 K Changes to slightly reddish white.
Custom Color Selects and adjusts your
own color scales:
●
R—sets your own red color levels
●
G—sets your
own green color levels
●
B—sets your own blue color levels
sRGB Sets your screen colors to adapt to the color standards used in
the image technology industry.
Language Selects the language in which the OSD menu is displayed. The
factory default is English.
Management Selects the power management features of the monitor.
Power Saver Enables the power saving feature. Select:
●
On
●
Off
The factory
default is On.
Power On Recall Restores power to the monitor following an unexpected removal
of power. Select:
●
On
●
Off
The factory default is On.
Mode Display
Power-On Status
Display
Displays the resolution, refresh rate and
frequency information
on the screen each time the OSD Main Menu is accessed.
Select:
●
On
●
Off
The
factory
default is On or Off, depending on the model.
Displays the operating status of the monitor each time the
monitor is powered on. Select the location to display the status
to:
●
Top
●
Middle
●
Bottom
●
Off
The
factory default is On or Off, depending on the model.
Adjusting the Monitor Settings 25

HP LP1965 Specifications

General

Operating temperature (T-T)	5 - 35 °C
Non-operating relative humidity (non-condensing)	5 - 90 %
Pivot angle	0 - 90 °
Plug and Play	Yes
Tilt angle range	-4 - 30 °
Height adjustment	100 mm
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
3D	No
HD type	-
Panel type	TFT
Pixel pitch	0.294 x 0.294 mm
Aspect ratio	4:3
Response time	6 ms
Display surface	Matt
Display diagonal	19 \
Display resolution	1280 x 1024 pixels
Display technology	LCD
Vertical scan range	48 - 76 Hz
Horizontal scan range	24 - 83 kHz
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Display scanning frequency	Horizontal frequency: 24-83 kHz, Vertical frequency: 48-76 Hz
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	1280 x 1024 (SXGA)
UNSPSC-code	43211902
Audio included	No audio included No audio included at platform level
Rear ports note	4 USB 2.0
Native resolution	SXGA (1280x1024) pixels
Security features	Kensington Lock-ready
Weight (imperial)	15.6 lb lbs
Power requirements	Auto-ranging, 90 to 265 VAC, Internal power supply, 50 to 60 Hz (built-in power supply)
Recommended resolution	Preset VESA Graphic Modes (non-interlaced): 1280 x 1024 @ 60 and 75 Hz, 1024 x 768 @ 60, 70 and 75 Hz, 1152 x 870 @ 75 Hz (Mac), 1152 x 900 @ 76 Hz (Sun), 832 x 624 @ 75 Hz (Mac), 800 x 600 @ 60, 72 and 75 Hz, 720 x 400 @ 70 Hz, 640 x 480 @ 60, 72 and 75
Display resolution at frequency	Preset VESA Graphic Modes (non-interlaced): 1280 x 1024 @ 60 and 75 Hz, 1024 x 768 @ 60, 70 and 75 Hz, 1152 x 870 @ 75 Hz (Mac), 1152 x 900 @ 76 Hz (Sun), 832 x 624 @ 75 Hz (Mac), 800 x 600 @ 60, 72 and 75 Hz, 720 x 400 @ 70 Hz, 640 x 480 @ 60, 72 and 75 Hz
Dimensions (W x D x H) (imperial)	15.9 x 8.78 x 18.79 \
Product dimensions (without stand, imperial)	15.9 x 2.4 x 12.96 \
Product color	Black, Silver
Country of origin	China
AC input voltage	90 - 265 V
AC input frequency	50 - 60 Hz
Power consumption (max)	55 W
Power consumption (standby)	2 W
Power consumption (typical)	35 W
I/O ports	One upstream, four downstream ports (cable included)
USB hub version	2.0
DVI-D ports quantity	0
DVI-I ports quantity	2
USB Type-A downstream ports quantity	3
Cables included	AC, DVI
Interface adapters included	DVI-I female - VGA male

Weight and Dimensions

Depth (with stand)	222.9 mm
Width (with stand)	403.9 mm
Height (with stand)	377.2 mm
Weight (with stand)	7060 g
Depth (without stand)	61 mm
Height (without stand)	329.1 mm
Weight (without stand)	4190 g
