HP LP2275w Service Manual

22" LCD Color Monitor HP LP2275w
61
705GQ893007 D953 ASS'Y
005G 42 1 CUSHION
012G 372 1 SILICONE RUBBER
D953 093G 52 60 DIODE YA868C15RSC 30A/150V TO-220
D953 093G 60320 DIODE SBR30150R 30A/150V TO-220
0M1G1730 8120 SCREW
HS7 Q90G 426501 HEAT SINK
IC901 056G 368 12 IC FAN7529MX SOP-8
IC903 056G 379 57 NCP1377BDR2G S0IC-8
IC902 056G 379 79 IC LD7522PS SOP-8
Q904 057G 417 4 PMBS3904/PHILIPS-SMT(04)
Q951 057G 417 4 PMBS3904/PHILIPS-SMT(04)
Q903 057G 417 6 PMBS3906/PHILIPS-SMT(06)
R912 061G0805100 RST CHIPR 10 OHM +-5% 1/8W
R944 061G0805100 RST CHIPR 10 OHM +-5% 1/8W
R959 061G0805100 2F RST CHIPR 10KOHM +-1% 1/8W
R961 061G0805100 2F RST CHIPR 10KOHM +-1% 1/8W
R948 061G0805102 RST CHIPR 1K OHM +-5% 1/8W
R937 061G0805102 RST CHIPR 1K OHM +-5% 1/8W
R936 061G0805102 RST CHIPR 1K OHM +-5% 1/8W
R962 061G0805102 RST CHIPR 1K OHM +-5% 1/8W
R975 061G0805103 RST CHIPR 10K OHM +-5% 1/8W
R963 061G0805103 RST CHIPR 10K OHM +-5% 1/8W
R957 061G0805103 RST CHIPR 10K OHM +-5% 1/8W
R945 061G0805103 RST CHIPR 10K OHM +-5% 1/8W
R935 061G0805103 RST CHIPR 10K OHM +-5% 1/8W
R932 061G0805103 RST CHIPR 10K OHM +-5% 1/8W
R928 061G0805103 RST CHIPR 10K OHM +-5% 1/8W
R911 061G0805103 RST CHIPR 10K OHM +-5% 1/8W
R917 061G0805130 2F RST CHIP 13K 1/8W 1%
R923 061G0805150 3F RST CHIP 150K 1/8W 1%
R960 061G0805150 3F RST CHIP 150K 1/8W 1%
R909 061G0805153 RST CHIPR 15KOHM +-5% 1/8W
R977 061G0805200 2F RST CHIPR 20 KOHM +-1% 1/8W
R927 061G0805220 RST CHIPR 22 OHM +-5% 1/8W
R954 061G0805222 RST CHIPR 2.2KOHM +-5% 1/8W
R974 061G0805222 RST CHIPR 2.2KOHM +-5% 1/8W
R908 061G0805224 RST CHIPR 220 KOHM +-5% 1/8W
R979 061G0805240 1F RST CHIPR 2.4K OHM +-1% 1/8W
R922 061G0805240 3F RST CHIPR 240 KOHM +-1% 1/8W

HP LP2275w Specifications

General

3D	No
Panel type	PVA
Pixel pitch	0.282 x 0.282 mm
Response time	6 ms
Display diagonal	22 \
Display resolution	1680 x 1050 pixels
Display technology	LCD
Vertical scan range	48 - 85 Hz
Horizontal scan range	30 - 93 kHz
Contrast ratio (typical)	1000:1
Display number of colors	-
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	1280 x 1024 (SXGA), 1440 x 900 (WXGA+), 640 x 480 (VGA), 800 x 600 (SVGA)
Storage temperature (T-T)	20 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Non-operating relative humidity (non-condensing)	5 - 90 %
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	85 W
Power consumption (standby)	2 W
Power consumption (typical)	56 W
Plug and Play	Yes
Tilt angle range	-5 - 30 °
Height adjustment	100 mm
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
USB hub version	2.0
HDMI ports quantity	0
USB Type-A downstream ports quantity	4
Product color	Black
Country of origin	China
Dimensions (W x D x H) (imperial)	19.9 x 10 x 18.8 \
Package weight	11300 g

Weight and Dimensions

Depth (with stand)	253 mm
Width (with stand)	506 mm
Height (with stand)	477 mm
Depth (without stand)	82.6 mm
Height (without stand)	328 mm
Weight (without stand)	8500 g
