HP LP2275w Service Manual

22" LCD Color Monitor HP LP2275w
62
R913 061G0805471 RST CHIPR 470 OHM +-5% 1/8W
R929 061G0805471 RST CHIPR 470 OHM +-5% 1/8W
R947 061G0805471 RST CHIPR 470 OHM +-5% 1/8W
R964 061G0805471 RST CHIPR 470 OHM +-5% 1/8W
R942 061G0805473 RST CHIPR 47K OHM +-5% 1/8W
R930 061G0805513 RST CHIPR 51K OHM +-5% 1/8W
R907 061G0805563 RST CHIPR 56K OHM +-5% 1/8W
R978 061G0805750 2F RST CHIPR 75 KOHM +-1% 1/8W
JP915 061G1206000 RST CHIP MAX 0R05 1/4W
JP914 061G1206000 RST CHIP MAX 0R05 1/4W
JP912 061G1206000 RST CHIP MAX 0R05 1/4W
JP911 061G1206000 RST CHIP MAX 0R05 1/4W
JP910 061G1206000 RST CHIP MAX 0R05 1/4W
JP909 061G1206000 RST CHIP MAX 0R05 1/4W
JP908 061G1206000 RST CHIP MAX 0R05 1/4W
JP907 061G1206000 RST CHIP MAX 0R05 1/4W
JP906 061G1206000 RST CHIP MAX 0R05 1/4W
JP905 061G1206000 RST CHIP MAX 0R05 1/4W
JP904 061G1206000 RST CHIP MAX 0R05 1/4W
JP903 061G1206000 RST CHIP MAX 0R05 1/4W
JP902 061G1206000 RST CHIP MAX 0R05 1/4W
JP901 061G1206000 RST CHIP MAX 0R05 1/4W
R919 061G1206100 4F RST CHIPR 1 MOHM +-1% 1/4W
R920 061G1206100 4F RST CHIPR 1 MOHM +-1% 1/4W
R921 061G1206100 4F RST CHIPR 1 MOHM +-1% 1/4W
R939 061G1206101 RST CHIPR 100 OHM +-5% 1/4W
R9105 061G1206104 RST CHIPR 100 KOHM +-5% 1/4W
R9106 061G1206104 RST CHIPR 100 KOHM +-5% 1/4W
R9107 061G1206104 RST CHIPR 100 KOHM +-5% 1/4W
R9108 061G1206104 RST CHIPR 100 KOHM +-5% 1/4W
R9109 061G1206104 RST CHIPR 100 KOHM +-5% 1/4W
R9110 061G1206104 RST CHIPR 100 KOHM +-5% 1/4W
R9111 061G1206104 RST CHIPR 100 KOHM +-5% 1/4W
R9112 061G1206104 RST CHIPR 100 KOHM +-5% 1/4W
R972 061G1206122 RST CHIPR 1.2 KOHM +-5% 1/4W
R973 061G1206122 RST CHIPR 1.2 KOHM +-5% 1/4W
R924 061G1206154 RST CHIPR 150K OHM +-5% 1/4W
R925 061G1206154 RST CHIPR 150K OHM +-5% 1/4W
R926 061G1206154 RST CHIPR 150K OHM +-5% 1/4W
R9113 061G1206159 RST CHIPR 1.5 OHM +-5% 1/4W

HP LP2275w Specifications

General

3D	No
Panel type	PVA
Pixel pitch	0.282 x 0.282 mm
Response time	6 ms
Display diagonal	22 \
Display resolution	1680 x 1050 pixels
Display technology	LCD
Vertical scan range	48 - 85 Hz
Horizontal scan range	30 - 93 kHz
Contrast ratio (typical)	1000:1
Display number of colors	-
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	1280 x 1024 (SXGA), 1440 x 900 (WXGA+), 640 x 480 (VGA), 800 x 600 (SVGA)
Storage temperature (T-T)	20 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Non-operating relative humidity (non-condensing)	5 - 90 %
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	85 W
Power consumption (standby)	2 W
Power consumption (typical)	56 W
Plug and Play	Yes
Tilt angle range	-5 - 30 °
Height adjustment	100 mm
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
USB hub version	2.0
HDMI ports quantity	0
USB Type-A downstream ports quantity	4
Product color	Black
Country of origin	China
Dimensions (W x D x H) (imperial)	19.9 x 10 x 18.8 \
Package weight	11300 g

Weight and Dimensions

Depth (with stand)	253 mm
Width (with stand)	506 mm
Height (with stand)	477 mm
Depth (without stand)	82.6 mm
Height (without stand)	328 mm
Weight (without stand)	8500 g
