HP LP2275w Service Manual

22" LCD Color Monitor HP LP2275w
63
R9114 061G1206159 RST CHIPR 1.5 OHM +-5% 1/4W
R940 061G1206229 RST CHIPR 2.2 OHM +-5% 1/4W
R938 061G1206229 RST CHIPR 2.2 OHM +-5% 1/4W
R931 061G1206229 RST CHIPR 2.2 OHM +-5% 1/4W
R9464 061G1206229 RST CHIPR 2.2 OHM +-5% 1/4W
R9463 061G1206229 RST CHIPR 2.2 OHM +-5% 1/4W
R9462 061G1206229 RST CHIPR 2.2 OHM +-5% 1/4W
R9461 061G1206229 RST CHIPR 2.2 OHM +-5% 1/4W
R934 061G1206479 RST CHIPR 4.7OHM +-5% 1/4W
R933 061G1206479 RST CHIPR 4.7OHM +-5% 1/4W
R916 061G1206680 3F RST CHIPR 680KOHM +-1% 1/4W
R915 061G1206680 3F RST CHIPR 680KOHM +-1% 1/4W
R914 061G1206680 3F RST CHIPR 680KOHM +-1% 1/4W
R903 061G1206684 RST CHIPR 680K OHM +-5% 1/4W
R902 061G1206684 RST CHIPR 680K OHM +-5% 1/4W
R901 061G1206684 RST CHIPR 680K OHM +-5% 1/4W
C934 065G0805102 32 CHIP 1000P 50VX7R 0805
C917 065G0805102 32 CHIP 1000P 50VX7R 0805
C910 065G0805102 32 CHIP 1000P 50VX7R 0805
C920 065G0805103 32 CAP CHIP 0805 10NF K 50V X7R
C922 065G0805103 32 CAP CHIP 0805 10NF K 50V X7R
C962 065G0805104 22 0.1UF +-10% 25V X7R 080
C968 065G0805104 22 0.1UF +-10% 25V X7R 080
C924 065G0805104 32 CAP CHIP 0805 0.1UF K 50V X7R
C958 065G0805104 32 CAP CHIP 0805 0.1UF K 50V X7R
C959 065G0805104 32 CAP CHIP 0805 0.1UF K 50V X7R
C961 065G0805104 32 CAP CHIP 0805 0.1UF K 50V X7R
C967 065G0805104 32 CAP CHIP 0805 0.1UF K 50V X7R
C970 065G0805104 32 CAP CHIP 0805 0.1UF K 50V X7R
C971 065G0805104 32 CAP CHIP 0805 0.1UF K 50V X7R
C907 065G0805105 37 CHIP 1UF 50V Y5V
C921 065G0805221 22 CHIP 220PF 25V X7R 0805
C933 065G0805221 22 CHIP 220PF 25V X7R 0805
C919 065G0805334 32 CHIP 0.33UF 50V X7R
C918 065G0805473 32 CHIP 0.047UF 50V X7R
C915 065G0805560 31 MLCC 0805 56PF J 50V NP0
C923 065G1206222 72 MLCC 1206 2200PF K 500V X7R
C935 065G1206222 72 MLCC 1206 2200PF K 500V X7R
C930 065G1206222 72 MLCC 1206 2200PF K 500V X7R
C937 065G1206222 72 MLCC 1206 2200PF K 500V X7R

HP LP2275w Specifications

General

3D	No
Panel type	PVA
Pixel pitch	0.282 x 0.282 mm
Response time	6 ms
Display diagonal	22 \
Display resolution	1680 x 1050 pixels
Display technology	LCD
Vertical scan range	48 - 85 Hz
Horizontal scan range	30 - 93 kHz
Contrast ratio (typical)	1000:1
Display number of colors	-
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	1280 x 1024 (SXGA), 1440 x 900 (WXGA+), 640 x 480 (VGA), 800 x 600 (SVGA)
Storage temperature (T-T)	20 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Non-operating relative humidity (non-condensing)	5 - 90 %
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	85 W
Power consumption (standby)	2 W
Power consumption (typical)	56 W
Plug and Play	Yes
Tilt angle range	-5 - 30 °
Height adjustment	100 mm
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
USB hub version	2.0
HDMI ports quantity	0
USB Type-A downstream ports quantity	4
Product color	Black
Country of origin	China
Dimensions (W x D x H) (imperial)	19.9 x 10 x 18.8 \
Package weight	11300 g

Weight and Dimensions

Depth (with stand)	253 mm
Width (with stand)	506 mm
Height (with stand)	477 mm
Depth (without stand)	82.6 mm
Height (without stand)	328 mm
Weight (without stand)	8500 g
