HP LP2275w Service Manual

22" LCD Color Monitor HP LP2275w
64
D903 093G 6432V LL4148-GSO8
D902 093G 6432V LL4148-GSO8
D904 093G 6432V LL4148-GSO8
D905 093G 6432V LL4148-GSO8
D910 093G 6432V LL4148-GSO8
ZD901 093G 39S 15 T RLZ15B LLDS
D907 093G 52S 9 T DIODE US1D-E3/63T 1A/200V DO-214AC
D908 093G 52S 9 T DIODE US1D-E3/63T 1A/200V DO-214AC
D907 093G 52S 11 T DIODE US1D 1A/200V SMA
D908 093G 52S 11 T DIODE US1D 1A/200V SMA
CN901 006G 31500 EYELET
IC953 056G 158 12 KIA431A-AT/P TO-92
IC954 056G 158 12 KIA431A-AT/P TO-92
IC953 056G 158901 IC TL431ACZ S (ST00) A
IC954 056G 158901 IC TL431ACZ S (ST00) A
R905 061G 30310852T GP FUSE RESISTOR
R9101 061G2SWJ10852T RST WWR 0.1OHM +-5% 2WS NKNP2WS
C925 067G 2151007NT KY50VB10M-TP5 5*11.5
C926 067G 2154707NT KY50VB47M-TP5 6.3*11
C927 067G 2154707NT KY50VB47M-TP5 6.3*11
C932 067G 2154707NT KY50VB47M-TP5 6.3*11
C936 067G 2154707NT KY50VB47M-TP5 6.3*11
F902 084G 55 4 FUSE 382-5A 250V WICKMANN
F901 084G 56 3W FUSE
D906 093G1100 1152T DIODE PR1007R 1A/1000V DO-41
D909 093G1100 1152T DIODE PR1007R 1A/1000V DO-41
J915 095G 90 23
JUMPER
J914 095G 90 23
JUMPER
J913 095G 90 23
JUMPER
J912 095G 90 23
JUMPER
J911 095G 90 23
JUMPER
J910 095G 90 23
JUMPER
J909 095G 90 23
JUMPER
J908 095G 90 23
JUMPER
J907 095G 90 23
JUMPER
J906 095G 90 23
JUMPER
J905 095G 90 23
JUMPER
J904 095G 90 23
JUMPER
J903 095G 90 23
JUMPER
J902 095G 90 23
JUMPER

HP LP2275w Specifications

General

3D	No
Panel type	PVA
Pixel pitch	0.282 x 0.282 mm
Response time	6 ms
Display diagonal	22 \
Display resolution	1680 x 1050 pixels
Display technology	LCD
Vertical scan range	48 - 85 Hz
Horizontal scan range	30 - 93 kHz
Contrast ratio (typical)	1000:1
Display number of colors	-
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	1280 x 1024 (SXGA), 1440 x 900 (WXGA+), 640 x 480 (VGA), 800 x 600 (SVGA)
Storage temperature (T-T)	20 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Non-operating relative humidity (non-condensing)	5 - 90 %
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	85 W
Power consumption (standby)	2 W
Power consumption (typical)	56 W
Plug and Play	Yes
Tilt angle range	-5 - 30 °
Height adjustment	100 mm
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
USB hub version	2.0
HDMI ports quantity	0
USB Type-A downstream ports quantity	4
Product color	Black
Country of origin	China
Dimensions (W x D x H) (imperial)	19.9 x 10 x 18.8 \
Package weight	11300 g

Weight and Dimensions

Depth (with stand)	253 mm
Width (with stand)	506 mm
Height (with stand)	477 mm
Depth (without stand)	82.6 mm
Height (without stand)	328 mm
Weight (without stand)	8500 g
