24" LCD Color Monitor HP LP2475w
31
7.2 Power Board
R946
0.2 OHM 2W
IC903
NCP1377BDR2G
1
2
3
4 5
6
8
Dmg
FB
CS
GND Drv
Vcc
HV
HS6 for
D953:
90G6241-1
ON/OFF
R971
100 OHM 1/4W
C952
0.0022uF
+24V
R973
1.2KOHM +-5% 1/4W
B+
C930
0.0022uF
C974
0.1uF
R944
10R 1/8W
+
C932
47uF/50V
R970
100 OHM +-5% 1/4W
IC955
PC123X2Y FZOF
12
43
T5A 250VAC
R9263
100KOHM +-5% 1/4W
C933
220PF/25V
+
C966
470uF/35V
+
C964
1000uF/35V
R940
2R2 1/4W
R978
75KOHM +-1% 1/8W
C931
NC
12V
01. MAINPOWER
C951
0.0022uF
D909
US1M-E3/61T
R943
NC
C967
0.1uF
R942
47KOHM +-5% 1/8W
D910
LL4148
D955
SR54
<Doc> A
<Title> B
22Tuesday , January 29, 2008
<PC B name>
<
称爹
>
OEM MODEL Size
Rev
Date
Sheet
of
TPV MODEL
PCB NAME
称爹
T P V ( Top Victory Electronics Co . , Ltd. )
Key Component
HS7 for
IC956:90G6084-1
R974
2.2KOHM +-5% 1/8W
T901
POWER X'FMR
1
2
4
5
6
8
9
11
12
IC956
SI-8120S
1
2
3
4
5
VIN
SWOUT
GND
VO
SS
R947
330 OHM +-5% 1/8W
R945
10K 1/8W
+24V
C972
HS4 for
Q905:
90G6064-1
D953
YG868C15R
1
2
3
R972
1.2KOHM +-5% 1/4W
F902
FUSE
C934
1N 50V
R9262
100KOHM +-5% 1/4W
ZD902
RLZ15B
1 2
+
C965
1000uF/35V
R9264
100K OHM 1/4W
R979
2.4KOHM +-1% 1/8W
CN904
CONN
1
2
3
4
5
6
7
8
9
10
11
12
13
14
+
C975
470uF/25V
G2956-C-X-X-1-080130
DIM
C976
0.1uF
N.C.
5V
12V
C968
0.1uF/25V
CN903
CONN
1
2
3
4
5
6
7
8
9
10
11
12
13
14
+
C973
470uF/35V
+24V
R977
20KOHM +-1% 1/8W
PS_ ON
L953
150uH
Q905
STP8NK80ZFP
R9261
100K OHM 1/4W
C970
0.1uF
R975
10K 1/8W
L952
3.3uH
IC954
AP431VLA
C937
0.0022uF
VCC2
