3. Insert the tool under the separation pad.
Figure 2-10 Remove the separation pad (Tray 1) (3 of 4)
4. Rotate the top of the tool away from the product to release the separation pad, and then remove the
tool and the separation pad together.
Figure 2-11 Remove the separation pad (Tray 1) (4 of 4)
Reinstallation tip You do not need to use the tool to install the new separation pad. Press the new pad
with your hand until it snaps into place and engages with the engine.
ENWW Removal and replacement procedures 93
