2. Loosen two thumb screws.
Figure 2-22 Remove the formatter (2 of 3)
3. Firmly pull the formatter from the product. Place the formatter on a clean, flat, grounded surface.
Figure 2-23 Remove the formatter (3 of 3)
Reinstallation tip If the formatter PCA was replaced, print a configuration page and make sure that
the serial number and page count information were transferred to the formatter PCA. If they were not,
use the Service menu to reset these values.
ENWW Removal and replacement procedures 101
