Right-front cover and control-panel assembly
1. Open the front door and the right door.
2. Remove two screws (callout 1), and then release two tabs (callout 2).
Figure 2-30 Remove the right-front cover and control-panel assembly (1 of 3)
1 2
3. Release 3 tabs (callout 1) on the right side of the assembly.
Figure 2-31 Remove the right-front cover and control-panel assembly (2 of 3)
1
108 Chapter 2 Removal and replacement ENWW
