HP M750 series

4. Support the assembly, release one cable retainer (callout 1), and then disconnect two connectors
(callout 2). Remove the assembly.
Figure 2-32 Remove the right-front cover and control-panel assembly (3 of 3)
1
2
ENWW Removal and replacement procedures 109
