HP M750 series

Top cover
Before proceeding, remove the following components:
●
Right-front cover and control-panel assembly. See
Right-front cover and control-panel assembly
on page 108.
●
Left cover. See
Left cover on page 110.
●
Remove the rear cover. See
Rear cover on page 111.
●
Right-rear cover. See
Right-rear cover on page 114.
Remove the top cover
1. Open the right-door assembly, and then remove four screws (callout 1).
Figure 2-40 Remove the top cover (1 of 2)
1
1
2. Open the toner-collection door.
ENWW Removal and replacement procedures 115
