Right-rear cover
1. Remove the rear cover. See Rear cover on page 111.
2. Open the right-door assembly.
3. Remove two screws (callout 1), release one tab (callout 2), and then remove the cover.
CAUTION: The ground spring on the back of the cover can easily be dislodged. Be careful not to lose it.
See
Reinstall the right-rear cover on page 114.
Figure 2-38 Remove the right-rear cover
1
2
Reinstall the right-rear cover
▲
Make sure that the ground spring (callout 1) is correctly installed before you reinstall the right-rear
cover.
Figure 2-39 Right-rear cover ground spring
1
114 Chapter 2 Removal and replacement ENWW
