HP M750 series

3. Rotate the access door down 90 degrees (callout 1), and then pull on the right side of the door (callout
2) to remove the access door.
Figure 2-37 Remove the toner collection unit access door (3 of 3)
1
2
ENWW Removal and replacement procedures 113
