Lifter-drive assembly
Before proceeding, remove the following components:
●
Tray 2 cassette.
●
Fuser. See
Fuser on page 90.
●
ITB. See
Intermediate transfer belt (ITB) on page 98.
●
1 x 500-paper feeder. See
1 x 500-sheet paper feeder assembly on page 211.
●
3 x 500-paper feeder (optional accessory). See
3 x 500-sheet paper feeder (optional accessory)
on page 225.
Remove the lifter-drive assembly
1. Verify that the right door is closed, and then turn the product so that the front side faces up.
Figure 2-70 Remove the lifter-drive assembly (1 of 3)
138 Chapter 2 Removal and replacement ENWW
