4. Release one of the registration sensor unit pivot hinges from the shafts (callout 1), pull out that end of
the assembly (callout 2), and then repeat the procedure on the other pivot hinge.
Figure 2-69 Remove the registration sensor assembly (4 of 4)
1
2
