3. Disconnect two connectors (callout 1), remove one screw (callout 2), and then remove the lifter drive
unit (callout 3).
Figure 2-72 Remove the lifter-drive assembly (3 of 3)
1
3
2
Reinstallation tip Make sure that the tabs align correctly when reinstalling the lifter-drive assembly.
140 Chapter 2 Removal and replacement ENWW
