HP M750 series - Page 206

2. Remove three screws (callout 1).
Figure 2-134 Remove the duplex-drive assembly (2 of 3)
1
3. Release one tab (callout 1), and then remove the assembly (callout 2).
Figure 2-135 Remove the duplex-drive assembly (3 of 3)
1
2
180 Chapter 2 Removal and replacement ENWW
