ITB motor (M1)
Before proceeding, remove the following components:
●
Toner-collection unit. See
Toner-collection unit on page 88.
●
Toner collection unit access door. See
Toner collection unit access door on page 112.
●
Rear cover. See
Rear cover on page 111.
●
Right-rear cover. See
Right-rear cover on page 114.
Remove the ITB motor
1. Disconnect all of the cables and FFCs from the DC controller (release the cables from the guides),
remove six screws (callout 1), and then remove the DC controller and the DC controller support.
Figure 2-139 Remove the ITB motor (1 of 2)
1
184 Chapter 2 Removal and replacement ENWW
