HP M750 series

2. Release four tabs (callout 1), and then unroute the cable (callout 2) as you remove the second transfer
high-voltage power supply (callout 3).
Figure 2-168 Remove the second transfer high-voltage power supply (2 of 2)
1
3
2
206 Chapter 2 Removal and replacement ENWW
