Environmental sensor
Before proceeding, remove the following components:
Right-front cover and control-panel assembly. See
Right-front cover and control-panel assembly
on page 108.
Remove the environmental sensor
1. Open the front door and the right door.
2. Disconnect one connector (callout 1), release one tab (callout 2), and then remove the environmental
sensor (callout 3).
Figure 2-172 Remove the environmental sensor
2
1
3
210 Chapter 2 Removal and replacement ENWW
