3 x 500 right and left cassette rails
1. Remove a cassette.
2. Remove two screws (callout 1), and then remove the 3 x 500 right (callout 2) and left (callout 3)
cassette rails. Repeat this procedure for the remaining cassette rails.
Figure 2-191 Remove the 3 x 500 right and left cassette rails
1
2
3
226 Chapter 2 Removal and replacement ENWW
