HP M750 series

3 x 500 right-door assembly
1. Open the right door, and then release one upper-link arm (callout 1).
Figure 2-201 Remove the 3 x 500 right-door assembly (1 of 3)
1
2. Release one tab (callout 1), and then remove the stopper (callout 2).
Figure 2-202 Remove the 3 x 500 right-door assembly (2 of 3)
1
2
234 Chapter 2 Removal and replacement ENWW
