3 x 500 right-lower cover 1
1. Remove the lowest cassette, and then remove the 3 x 500 right door assembly (see 3 x 500 right-door
assembly on page 234).
2. Remove three screws (callout 1), loosen the top portion of the cover, and then remove the 3 x 500 right-
lower cover 1.
Figure 2-204 Remove the 3 x 500 right-lower cover 1
1
236 Chapter 2 Removal and replacement ENWW
