Locations of major components
Figure 3-35 External component locations
1
2
3
4
5
6
7
9
8
Item Description Item Description
1 Right-rear cover 6 Top cover
2 Right-door assembly 7 Left cover
3 Right-front cover 8 Rear cover
4 Front-door assembly 9 Toner collection unit access-door
5 Cassette (Tray 2)
ENWW Tools for troubleshooting 321
