Figure 3-37 Major component locations (2 of 3)
1
2
3
4
5
6
7
8
9
Item Description Item Description
1 ITB front guide unit 6 Duplex drive unit (duplex models only)
2 ITB rear guide unit 7 Delivery drive unit (simplex models only)
3 Delivery unit 8 Cassette (Tray 2)
324 Chapter 3 Solve problems ENWW
