Item Description Item Description
4 Toner collection unit full sensor 9 ITB unit
5 Cassette pickup drive unit
Figure 3-38 Major component locations (3 of 3)
1
2
3
Item Description
1 Waste toner carrier unit
2 Formatter
3 Fuser drive unit
ENWW Tools for troubleshooting 325
