Figure 3-39 Motors, fans, and rollers component locations
1
2
3
4
5
6
7
8
9
10
11
12
Item Description Item Description
1 Secondary transfer roller unit 7 Drum motor
2 MP tray (Tray 1) pickup roller 8 Fuser motor
3 MP tray (Tray 1) separation pad 9 ITB motor
4 Cassette (Tray 2) separation roller unit 10 Developing disengagement motor
326 Chapter 3 Solve problems ENWW
