Paper-feeder motors
The paper feeder has two motors for paper feed and cassette lift-up operation.
Figure 1-50 Paper-feeder motors
PF lifter motor (M2)
PF pickup motor (M1)
Table 1-10 Paper-feeder motors
Motor Driving part Failure detection
PF pickup motor (M1) PF pickup roller
PF separation roller
PF feed roller
No
PF lifter motor (M2) Lifter for the PF cassette No
68 Chapter 1 Theory of operation ENWW
