Power connector cable
Description Spare part number
Power connector cable 589682-001
Before removing the power connector cable, follow these steps:
1.
Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2.
Disconnect all external devices connected to the computer.
3.
Disconnect the power from the computer by first unplugging the power cord from the AC outlet
and then unplugging the AC adapter from the computer.
4.
Remove the battery (see
Battery on page 38).
5.
Remove the service cover (see
Service cover on page 40).
6.
Disconnect the hard drive cable from the system board (see
Hard drive on page 43).
7.
Disconnect the WWAN antenna cables from the WWAN module (see
WWAN module
on page 45).
8.
Disconnect the WLAN antenna cables from the WLAN module (see
WLAN module on page 47).
9.
Remove the following components:
a.
Keyboard (see
Keyboard on page 52).
b.
Top cover (see
Top cover on page 56).
c.
Display assembly (see
Display assembly on page 61).
d.
System board (see
System board on page 64).
Remove the power connector cable:
1. Remove the Phillips PM2.0×4.0 screw (1) that secures the power connector and bracket to the
base enclosure.
2. Remove the power connector bracket (2).
NOTE: The power connector bracket is included in the base enclosure spare part kit, spare part
number 608306-001.
Component replacement procedures
69
