Item Description Spare part number
In red 589687-001
In silver 589686-001
(4) TouchPad (includes cable and bracket (4b)):
For use only with black top cover 589677-001
For use only with blue top cover 589685-001
For use only with red top cover 589684-001
For use only with silver top cover 589683-001
(5) Speakers (includes cable) 596153-001
(6) System board (includes Intel Atom N450 1.66-GHz processor with 512-KB level 2 cache, 667-MHz FSB and
replacement thermal material):
Includes Digital Media Card Reader 589638-001
Does not include Digital Media Card Reader 589639-001
(7) Fan/heat sink assembly (includes replacement thermal material) 589681-001
(8) Power connector cable 589682-001
(9) Base enclosure (includes 4 rubber feet and power connector bracket) 589678-001
Rubber Kit (not illustrated, includes 4 rubber feet and RJ-45 cover) 589680-001
(10) Memory module (667-MHz, DDR2):
2048-MB 589666-001
1024-MB 589665-001
(11) RTC battery 449729-001
(12) WLAN module
Atheros 9285G 802.11b/g/n 1×1 WiFi Adapter module:
● For use in Canada, the Cayman Islands, Guam, Puerto Rico, the U.S. Virgin Islands,
and the United States
518436-001
18 Chapter 3 Illustrated parts catalog
