3. Release the WLAN antenna cables (1) from the clips built into the base enclosure (2).
4. Turn the computer right-side up, with the front toward you.
5. Open the computer as far as it will open.
6. Disconnect the display panel cable (1) from the system board.
7. Release the wireless antenna cables (2) from the clip built into the base enclosure.
CAUTION: Support the display assembly when removing the following screws. Failure to
support the display assembly can result in damage to the display assembly and other device
components.
Component replacement procedures 59
