HP MINI 5103 Maintenance And Service Guide

Category Description
●
320-GB, 7200-RPM
NOTE: Not supported by computers with Windows 7 Home Basic or with
Windows 7 Starter in select countries and regions.
●
250-GB, 7200-RPM
●
160-GB, 7200-RPM
Solid state drive (SSD)
Supports the following 6.35-cm (2.50-in) SATA solid state drives:
●
80 GB
NOTE: Not supported by computers with Windows 7 Starter.
●
128 GB
NOTE: Not supported by computers with Windows 7 Starter.
Optical drive Supports external USB optical drives only
Diskette drive Supports external USB diskette drives only
Audio/Visual High-definition (HD) audio
Integrated speakers (2)
Fixed integrated stereo microphones (2)
Fixed integrated 2-MP webcam
Modem Supports external USB modems only
Ethernet Integrated 10/100/1000 Wake-On-LAN network interface card (NIC)
Wireless 2 WLAN antennas built into display assembly. WWAN antennas (2) with WWAN
option (worldwide 5-band antenna configured with select models)
Integrated WLAN modules:
●
802.11/a/b/g/n
●
802.11 b/g/n
●
802.11b/g/n with Bluetooth
Support for No WLAN option
Integrated WWAN option
NOTE: Not supported by computers with Linux installed.
NOTE: Not supported by computers with HD Enhanced Video Accelerator
installed.
Integrated WPAN Bluetooth® module
Support for No WPAN option.
External media cards Media Card Reader with push-push technology supporting:
●
MultiMediaCard (MMC)
●
Secure Digital (SD) Memory Card
2 Chapter 1 Product description

HP MINI 5103 Specifications

General

Graphics	Intel GMA 3150
Webcam	Integrated 2 MP webcam
Processor	Intel Atom N455 (1.66 GHz), Intel Atom N475 (1.83 GHz)
Display	10.1-inch diagonal LED-backlit HD (1366 x 768)
RAM	Up to 2 GB DDR3
Storage	160 GB HDD
Operating System	Windows 7 Starter
Battery	3-cell or 6-cell Lithium-Ion battery
Weight	2.64 lbs (1.2 kg)
Dimensions	10.3 x 7.1 x 0.9 inches
Wireless	802.11b/g/n
Ports	3 x USB 2.0, VGA
Card Reader	SD/MMC
Keyboard	95% full-size
