HP MINI 5103 Maintenance And Service Guide

Item Description Spare part number
(2) Display hinge kit
(Includes left and right display panel hinges)
577930-001
(3) LCD panel
NOTE: The non-touch display assembly includes the LCD panel. See the display
assembly part number in
Device major components on page 18.
●
LCD with touch glass for use with high definition display assembly 624216-001
●
LCD with touch glass for use with WSVGA display assembly 624218-001
(4) Webcam module 577927-001
(5) Display panel/webcam cable for use in:
●
High-definition display assembly 577932-001
●
WSVGA display assembly 577931-001
●
High-definition display assembly w/ touchscreen 617082–001
●
WSVGA display assembly w/ touchscreen 617081–001
Display cable kit includes the following cables: 577933-001
(6)
●
WLAN antennas (2) with cable
(7)
●
Dual microphone with cable
(8)
●
WWAN antennas (2) with cable
(9) Display back cover (includes logo)
●
Espresso for use with touch screen 625724-001
●
Red for use with touch screen 598458-001
●
Blue for use with touch screen 598459-001
●
Espresso for use with non-touch screen 625725-001
●
Red for use with non-touch screen 606201-001
●
Blue for use with non-touch screen 606970-001
24 Chapter 3 Illustrated parts catalog

HP MINI 5103 Specifications

General

Graphics	Intel GMA 3150
Webcam	Integrated 2 MP webcam
Processor	Intel Atom N455 (1.66 GHz), Intel Atom N475 (1.83 GHz)
Display	10.1-inch diagonal LED-backlit HD (1366 x 768)
RAM	Up to 2 GB DDR3
Storage	160 GB HDD
Operating System	Windows 7 Starter
Battery	3-cell or 6-cell Lithium-Ion battery
Weight	2.64 lbs (1.2 kg)
Dimensions	10.3 x 7.1 x 0.9 inches
Wireless	802.11b/g/n
Ports	3 x USB 2.0, VGA
Card Reader	SD/MMC
Keyboard	95% full-size
