HP MINI 5103 Maintenance And Service Guide

Spare part number Description
625729–001 Display panel assembly, 25.7-cm (10.1-in), WSVGA, AntiGlare display assembly for use with
webcam and WWAN option, espresso
625730–001 Display panel assembly, 25.7-cm (10.1-in), high-definition, AntiGlare display assembly for use with
webcam and WWAN option, espresso
626582–001 System board (including replacement thermal material and RTC battery), Intel Atom N455 1.66-
GHz processor, 512-KB Level 2 cache, 667-MHz front-side bus (FSB) for use in the People's
Republic of China and Russia
626583–001 System board (including replacement thermal material and RTC battery), Intel Atom N475 1.83-
GHz processor, 512-KB Level 2 cache, 667-MHz front-side bus (FSB) for use in the People's
Republic of China and Russia
626584–001 System board (including replacement thermal material and RTC battery), Intel Atom N550 1.50-
GHz processor, 512-KB Level 2 cache, 667-MHz front-side bus (FSB) for use in the People's
Republic of China and Russia
627790–001 Dual-core fan and heat sink assembly with replacement thermal material
627791–001 HD Video Decoder
627792–001 Dual-core top cover with TouchPad, espresso
30 Chapter 3 Illustrated parts catalog

HP MINI 5103 Specifications

General

Graphics	Intel GMA 3150
Webcam	Integrated 2 MP webcam
Processor	Intel Atom N455 (1.66 GHz), Intel Atom N475 (1.83 GHz)
Display	10.1-inch diagonal LED-backlit HD (1366 x 768)
RAM	Up to 2 GB DDR3
Storage	160 GB HDD
Operating System	Windows 7 Starter
Battery	3-cell or 6-cell Lithium-Ion battery
Weight	2.64 lbs (1.2 kg)
Dimensions	10.3 x 7.1 x 0.9 inches
Wireless	802.11b/g/n
Ports	3 x USB 2.0, VGA
Card Reader	SD/MMC
Keyboard	95% full-size
