Category Description
Primary storage M.2 solid-state drives (2280):
128 GB, SATA-3, SS, TLC
Audio and video HP Bang & Olufsen Audio
Multi-array microphone (including World-Facing 3rd microphone)
Stereo speakers (2) (13 mm × 38 mm × 4 mm)
Camera HD RGB 720p (select models only)
Camera HD + IR RGB 720p (select models only)
Camera privacy shutter (only with non-touch camera panels)
Supports WDR (Wide Dynamic Range)
Ethernet Realtek PCIe GbE Family Controller 10/100/1000 with DASH Support
RTL8111EPH-CG
The following support S3/S4/ wake on LAN: embedded NIC.
*The following support S3/S5 wake on LAN/HBMA (via out of band): HP Elite USB-C Dock G3, HP USB-C Dock G4,
HP USB-C Universal Dock, HP Thunderbolt Dock 120 W, and HP USB-C Mini Dock.
* The following support S3 wake on LAN/HBMA (via Windows® operating system): HP Elite USB-C Dock G2, HP
Executive Travel Hub, HP 301 Travel Adapter.
Wireless
networking
WPAN Bluetooth:
Integrated wireless personal area network (PAN) supported by Bluetooth
®
4.2 combo card
Wireless local area network (WLAN) (select models only):
Integrated WLAN options with dual antennas (M.2 2230 socket PCIe/USB)
Supports the following WLAN formats:
● Intel Dual band wireless-AC 8265 802.11ac 2×2 WiFi + Bluetooth 4.2 Combo Adapter (non-vPro)
Two WLAN antennas built into bottom of display assembly
Compatible with Miracast-certied devices
Bluetooth Disabled IOPT
Support S3 wake on Wireless LAN
Supports WLAN/LAN/WWAN switching
Support HP Sure Connect with Client Side Load Balancing
Near-Field Communication (NFC) (select models only):
NXP NPC300 Near Field Communication Module (NFC Mirage WNC XRAV-1 [NXP NPC300 I2C 10 mm x 17 mm])
NFC antenna
Wireless wide area network (WWAN) (select models only):
Integrated wireless wide area network (WWAN) options by way of wireless module
Two WWAN antennas (world wide 5 band, congured at top of display panel)
Supports the following WWAN formats:
2 Chapter 1 Product description
