Item Component Spare part number
(1) Display assembly
Display assemblies are spared at the subcomponent level only. For more display
assembly spare part information, see Display assembly subcomponents on page 22.
not spared as whole hinge-up
(2) Touch not spared as whole hinge-up
(3) Keyboard (see Keyboard on page 42)
For a list of keyboard country codes, see Keyboard on page 42.
Without a backlight L14379-xx1
With a backlight L14377-xx1
With a backlight, privacy L14378-xx1
(4) Top cover L21975-001
(5) RJ-45 board with bracket L14386-001
(6) TouchPad
For use in models without an NFC module L14381-001
For use in models with an NFC module L19417-001
(7) TouchPad button board L18311-001
(8) RTC battery L17255-001
(9) Power button board L14374-001
(10) USB board L14380-001
(11) USB board bracket L14380-001
(12) Fingerprint reader assembly (includes cable) L13681-001
(13) NFC module (includes antenna and TouchPad foam) L14385-001
(14) Speakers (includes cable) L13684-001
(15) Smart card reader board L18312-001
(16) System board (includes processor and replacement thermal material, see System board on page 63)
AMD Ryzen 3 PRO 2300U Mobile Processor L29298-301
(17) Fan L22306-001
(18) Heat sink L14372-001
(19) Memory module (DDR-2400)
4-GB 862397-850
(20) WLAN/Bluetooth combo card
Intel Dual band wireless-AC 8265 802.11AC 2x2 WiFi + Bluetooth 4.2 Combo Adaptor
(non-vPro)
851594-001
(21) WWAN module
LTE CAT4: Huawei HP lt4132, LTE/HSPA+ w/GPS 845710-003
LTE CAT9: Fibocom lt4210 LTE/HSPA+ w/GPS 917823-001
Computer major components 21
