Item Component Spare part number
For use in models with an HD camera (includes camera shutter) L15506-001
For use in models with an IR camera (includes camera shutter) L15507-001
Camera shutters (IR and HD cameras; not illustrated) L15503-001 (Plastics Kit)
(2) Raw panel
FHD, non-touch L22310-001
FHD, non-touch, models with IR and HD cameras and WWAN modules L22309-001
FHD, touch, models with IR and HD cameras and WWAN modules L22311-001
(3) Hinge cover
For use in models with touch displays L14375-001 (Hinge Kit)
For use in models with non-touch displays L14376-001 (Hinge Kit)
(4) Camera module
HD camera L28405-001
IR camera L28404-001
Microphone module (includes double-sided tape; not shown) L15512-001
(5) Camera cable (HD and IR models) L14370-001 (Cable Kit)
(6) Hinges (left and right) (for use in models with touch displays) L14375-001 (Hinge Kit)
Hinges (left and right) (for use in models with non-touch displays) L14376-001 (Hinge Kit)
(7) WLAN antenna (spared with display enclosure)
(8) WWAN antenna (spared with display enclosure)
(9) Display cable L14370-001 (Cable Kit)
(10) Display enclosure (includes tape, gasket, and foam for display)
For use in models without a WWAN module L15501-001
For use in models with a WWAN module L15502-001
Display assembly subcomponents 23
