b. Remove the display from the enclosure (2).
The display enclosure is available using spare part number 788597-001.
NOTE: The display enclosure spare part kit also includes the display hinge kit.
The Display Panel Kit is available using spare part number 788608-001.
NOTE: The Display Panel Kit must be assembled in a clean room.
5. To disconnect the display cable from the display panel:
a. Rotate the display downward so it lays flat (1).
b. Lift the tape from atop the connector on the back of the display panel (2), and then disconnect the
display cable from the connector (3).
Display assembly 43
