Item Component Spare part number
For use in Belgium L14994-A41
For use in Korea L14994-AD1
For use Internationally L14994-B31
For use in Slovenia L14994-BA1
For use in Israel L14994-BB1
For use in Switzerland L14994-BG1
For use in Canada L14994-DB1
For use in Nordic Regions L14994-DH1
For use in Czech/Slovakia L14994-FL1
(3) TouchPad click button board and cable 931594-001
(4) TouchPad board 929472-001
(5) Speaker (includes wire connected left and right speakers) 931598-001
(6) Power button board (cable spared separately as 931561-005) 931590-001
(7) USB board (cable spared separately as 931560-005)
For units equipped with NVIDIA N17E (GTX1070/GTX 1060) L14990-001
For units equipped with NVIDIA N17P (GTX1050/GTX 1050Ti) L14989-001
(8) Power in connector (cable is spared separately as 931561-001)
For products equipped with a 135 W adapter, and NV N17P (GTX 1050/GTX 1050Ti)
processors
926204-002
For products equipped with a 230 W adapter, and NV N17E (GTX 1070/GTX 1060) 926564-001
(9) Power in connector bracket ( for products equipped with a 135 W adapter only. Products
with a 230 W adapter do not have a bracket)
931582-001
(10) System board (includes processor and replacement thermal material):
All system boards use the following part numbers:
xxxxxx-001 Non-Windows operating systems
xxxxxx-601 Windows 10 operating systems
NVIDIA N17E-G2 (GeForce GTX 1070), 8 GB i7-8750H L11136-xxx
NVIDIA N17E-G1 (GeForce GTX 1060), 6 GB i7-8750H L11137-xxx
NVIDIA N17E-G1 (GeForce GTX 1060), 3 GB i7-8750H L18941-xxx
NVIDIA N17P-G1 (GeForce GTX 1050Ti), 4 GB i7-8750H L11139-xxx
NVIDIA N17P-G0 (GeForce GTX 1050), 4 GB i7-8750H L11140-xxx
NVIDIA N17P-G0 (GeForce GTX 1050), 4 GB i5-8300H L11141-xxx
NVIDIA N17P-G0 (GeForce GTX 1050), 2 GB i7-8750H L11142-xxx
NVIDIA N17P-G0 (GeForce GTX 1050), 2 GB i5-8300H L11143-xxx
NVIDIA N17E-G1 (GeForce GTX 1060), 6 GB i5-8300H L11138-xxx
Computer major components 25
