Hard drive
Description Spare part number
Hard drive
●
2 TB 5400 RPM SATA RAW HYBRID 7 mm 929167-850
●
2 TB 5400 RPM SATA RAW 7 mm 912487-850
●
1 TB 7200 RPM SATA RAW 9.5 mm 766644-001
Hard drive connector and cable 931564-001
Before removing the hard drive, follow these steps:
1. Turn o the computer. If you are unsure whether the computer is o or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by rst unplugging the power cord from the AC outlet and then
unplugging the AC adapter from the computer.
3. Disconnect all external devices from the computer.
4. Remove the following components:
a. Base enclosure (see Base enclosure on page 45)
b. Battery (see Battery on page 38)
Remove the hard drive:
NOTE: Use minimal force when lifting the locking bar up on the ZIF connector and disconnecting the cable.
1. Open the zero insertion force (ZIF) connector to release the hard drive cable (1) from the system board.
2. Remove the hard drive connector cable from the ZIF connector (2) .
3. Lift the top edge of the hard drive upward (3).
40 Chapter 5 Removal and replacement procedures for Customer Self-Repair parts
