Trunks
Description Spare part number
Left trunk 931595-001
Right trunk 931596-001
Before removing the trunks, follow these steps:
1. Turn o the computer. If you are unsure whether the computer is o or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by rst unplugging the power cord from the AC outlet and then
unplugging the AC adapter from the computer.
3. Disconnect all external devices from the computer.
4. Remove the following components:
a. Base enclosure (see Base enclosure on page 45)
b. Battery (see Battery on page 38)
Optical drive (see Optical drive on page 48)
c. Speakers (see Speakers on page 47)
Remove the trunks:
1. Remove eight Phillips screws (1) securing the trunks.
2. Remove the trunks (2).
Reverse this procedure to install the trunks.
Component replacement procedures 49
