3. Remove the WLAN module (3) by pulling the module away from the slot at an angle.
NOTE: WLAN modules are notched to prevent incorrect installation.
NOTE: If the WLAN antenna cables are not connected to the terminals on the WLAN module, protective
sleeves should be installed on the antenna connectors, as shown in the following illustration.
Reverse this procedure to install the WLAN module.
Component replacement procedures 51
