HP OMEN 27q - Removal and Replacement Procedures; Preparation for Disassembly; Rear Cover Removal

8
How to order parts
The HP authorized repair center can purchase the power board from HP.
Power board
Description
HP spare part number
Manufacturer part number
PSU OMEN 27q (1
st
source)
N49785-001
PLPCMH292GACN
PSU OMEN 27q (2
nd
source)
N49785-002
PLPCMH572KACM
Capacitors and connectors are available for purchase from the following EU distributors:
 RS Component: Capacitors | RS Components (rs-online.com)
 Farnell: Farnell UK - Electronic Components Distributor
 Rubycon: Capacitors | RS Components (rs-online.com)
Capacitors by distributor
Component description
Location
Component
distributor
Distributor part number
EC 470uF 20% 25V
10x12 3000 hr 1.6A
PY1E
C9116/C9113/C9114/
C9115/C8601/C9117
Rubycon
25ZLH470MEFC10X12.5
Connectors by manufacturer
Component description
Location identifier
Component
distributor
Distributer part number
HDMI
CN501/CN502
RS
SD-47151-001
(Molex)
DP
CN503
Farnell
DP1RD20JQ1
(JAE)
PHONE JACK
CN601
RS
913-1021
(RS PRO)
12
KEY BOARD
1
13
KEY_POWER
1
14
KEY_FUNCTION
1
15
KEY
1
16
REAR_COVER L27W-Ghp3-p3
1
17
DECO_REAR_COVER N/A
1
18
Cover_Led N/A
1
19
BKT_VESA
1
20
SCREW M4 10
4
21
COVER_VESA L27WA-Ghp3b-p3
1
22
stand ass'y L27W-Ghp3-p3 NA
1
23
stand clamp N/A NA
1
24
BASE_ASS’Y NA N/A
1
