Left
NOTE: Your computer may look slightly different from the illustration in this section.
Component Description
(1)
Power connector Connects an AC adapter.
(2)
1394 port Connects an optional IEEE 1394 or 1394a device, such as
a camcorder.
(3)
USB 3.0 ports (2) Connect optional USB 3.0 devices and provide enhanced
USB power performance.
(4)
HP ExpressCard slot or smart card reader
(depending on configuration)
Supports optional ExpressCards or smart cards.
(5) Media Card Reader Reads data from and writes data to digital memory cards
such as Secure Digital (SD).
(6) Upgrade bay (optical drive shown) The upgrade bay can hold either a hard drive or an optical
drive that reads and writes (select models only) to an
optical disc. It can also hold a weight saver option.
(7) Optical drive eject button Releases the optical drive disc tray.
Left 11
