HP Omnibook XE4100/XE4500 Removal and Replacement 2-11
4. If necessary, while holding the center of the cover, carefully insert the flat-blade screwdriver under
the right side of the display assembly hinge, gently pry up, and then lift the cover out. This
procedure might need to be repeated on the left side of display assembly hinge to completely
remove the cover.
Figure 2-7. Removing the Keyboard Cover
Reassembly Note
• Insert the tabs on the left- and right-center of the panel into the mating slots under the keyboard,
and then press the panel into place.
Screw, M2.5×4mm (2)
