HP P4819

P4819(E) 5-2
REF.NO. PART NO. DESCRIPTION REMARK
7
8
12
10
9
13
11
5
6
1
3
4
15
5-1. CHASSIS
z 7-685-881-09 +BVTT 4X8
s 7-685-646-79 +BVTP 3X8
x 7-685-647-79 +BVTP 3X10
a 7-685-663-71 +BVTP 4X16
1 * 8-933-515-00 A1 BOARD, COMPLETE
3 4-079-817-41 CABINET
4 * 4-085-554-01 LABEL, INFORMATION
[U/C, AEP, J, CH]
4 * 4-085-554-11 LABEL, INFORMATION [SH]
5 4-635-966-01 SCREW (HEX)
6 4-052-345-01 SCREW, (3X8) (+K), TAPPING
7 0 1-251-382-31 INLET, AC (WITH NOISE FILTER)
8 0 1-453-359-11 TRANSFORMER ASSY, FLYBACK
(NX-4702/KM7E)
9 * 8-933-476-00 DA BOARD, COMPLETE
10 * 8-933-517-00 N BOARD, COMPLETE
11 * 8-933-481-00 L2 BOARD, COMPLETE
12 * 8-933-516-00 D BOARD, COMPLETE
13 4-079-799-01 BAR, EXTENSION
15 3-704-372-01 HOLDER, HV CABLE
