d. Remove the display bezel (4) from the display assembly.
The display bezel is available spare part numbers L19182-001 (for use only on computer models
equipped with an FHD infrared camera) and L19181-001 (for use only on computer models equipped
with an HD non-infrared camera).
9. If it is necessary to replace the camera/microphone module:
a. Disconnect the cable (1) from the camera/microphone module.
NOTE: Cables connect to both sides of the FHD infrared camera. A single cable connects to only one
side of the HD camera.
56 Chapter 5 Removal and replacement procedures for Authorized Service Provider parts
