HP Pavilion 17 Series User Manual

5. To remove the wireless antenna cables and transceivers, release the wireless antenna cables from the
clips (1) built into the display enclosure, peel the transceivers from the enclosure (2), and then remove
the antenna cables and transceivers (3).
The antennas are available using spare part number 811201-001.
NOTE: Number of antennas and transceivers may vary.
6. To remove the display/webcam cable, disconnect the cable (1).
7. Remove the cable from the clips built into the display panel (2), and then remove the cable from the
display (3).
8. If replacing the display enclosure, be sure that the subcomponents (including the webcam/microphone
module, the antenna receivers, and all associated cables and hardware) are transferred to the new
enclosure.
Reverse this procedure to reassemble and install the display assembly.
66 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts

HP Pavilion 17 Series Specifications

General

Display Size	17.3 inches
Processor Options	Intel Core i5/i7
Storage Options	HDD + SSD
Graphics	Intel UHD Graphics, NVIDIA GeForce or AMD Radeon Graphics
Operating System	Windows 10
Weight	2.8 kg
Display Resolution	1920 x 1080 (Full HD)
Optical Drive	DVD-RW
Ports	HDMI, headphone/microphone combo
Wireless	802.11ac Wi-Fi; Bluetooth
Battery	4-cell Li-ion
RAM	16GB DDR4
